Standing Seam Sheet Metal
SingleRail 36
Product number:
2004258
MCS Certified Mounting rail with side-connection and static confirmation in K2 Base. Can be used variably for different roof connections. Length: 3.65 m. Material: Aluminium EN AW-6063 T66
SingleRail 36; 4.80 m, black anodised
Product number:
2004396
Mounting rail with side-connection and static confirmation in K2 Base. Can be used variably for different roof connections. Length: 4.80 m. Material: aluminium EN AW-6063 T66, black anodized. Eloxal may show slight scratches as a result of packaging and transport.
SolidRail UltraLight
Product number:
2004264
MCS Certified Mounting rail with static confirmation in K2 Base. Can be used variably for different roof connections. Material: aluminium EN AW-6063 T66
SolidRail Light
Product number:
2004269
Mounting rail with static confirmation in K2 Base. Can be used variably for different roof connections. Length 3.65 m. Material: aluminium EN AW-6063 T66
SolidRail Light; 4.80 m, black anodised
Product number:
2004397
Mounting rail with static confirmation in K2 Base. Can be used variably for different roof connections. Length 4.80 m. Material: aluminium EN AW-6063 T66, black anodized. Eloxal may show slight scratches as a result of packaging and transport.
S-5! E-Mini-FL Standing SeamClamp
Product number:
1001052
S-5! SeamClamp for fastening of K2 SolidRail on double-folded standing seams metal roofs. With socket set screw. With General approval. Material: aluminium
Standing Seam Clamp CF:x SingleRail
Product number:
2003024
Seam clamp for mounting the SingleRail on double folded standing seams made of titanium zinc, aluminum, stainless or galvanized steel. Material: clamp: aluminum, screws: stainless steel A2
Double standing seam clamp SolidRail
Product number:
2001712
Metal seam clamp with round hole for fixing the K2 SolidRail on metal seam roofs with double standing seam. Clamping range: 3,5 mm. Material: stainless steel A2
Round SeamClamp; SolidRail
Product number:
2001853
Metal seam clamp with round hole for fixing the K2 SolidRail on metal seam roofs with round seam. Material: stainless steel A2
Round Seam Clamp CF:x SingleRail
Product number:
2002859
Seam clamp for mounting the SingleRail on various round bulb seams such as Kalzip, Bemo, Aluform or RIB-ROOF Evolution. Material: clamp: aluminum, screws: stainless steel A2
Round Seam Clamp S-5! SolidRail
Product number:
1000888
S-5! SeamClamp for fastening of K2 SolidRail on rounded standing seam metal roofs. Two-part-construction with fitting part. With socket set screw. With General approval. Material: aluminium
Snap Seam Clamp CF:x SolidRail
Product number:
2003082
Seam clamp for fixing the K2 SolidRail on seam roofs with angled seam or snap seam. Article K2 Adapter plate M10 (2002544) is required for rail mounting. Material: Clamp: Aluminium; Screws: Stainless steel A2
Snap Seam Clamp CF:x SingleRail
Product number:
2003083
Seam Clamp for SingleRail mounting on angled seam and snap seam Profilees. Material: clamp: aluminium, screws: stainless steel A2
Metal roof system clamp RibRoofEvolution
Product number:
2002226
Solar bracket for fixing the K2 SolidRail for Zambelli Rib-Roof Evolution metal roof systems with round seam. Diameter: 23 mm. Material: Aluminium EN AW-6063 T66
Metal roof system clamp RibRoofSpeed500
Product number:
2002225
Solar bracket for fixing the K2 SolidRail to Zambelli Rib-Roof Speed 500 metal roof systems with standing seam. Opening dimension: 17 mm. Material: Aluminium EN AW-6063 T66
Metal roof system clamp Zambelli RibRoof465
Product number:
2002118
Solar bracket for mounting the K2 SolidRail on Zambelli RIB-Roof 465 metal roof systems with standing seam. Opening dimension: 12 mm. Material: Aluminium EN AW-6063 T66
Universal KL-Clamp
Product number:
2004124
K2 sheet metal seam clamp for Klip-Lok 700 Hi-strength® and Klip-Lok Optima® 700 (Lysaght ™) sheet metal roofing; KingKlip® 700 (Fielders®); Klip-Lok® 406 (Lysaght ™). With direct connection option for K2 module clamps. Material: Aluminium EN AW 6063-T66
Rail connector Set SingleRail 36
Product number:
2001976
MCS Certified Rail connector set as connecting element between two K2 SingleRails 36. screw included. Material: Aluminium EN AW-6063 T66, stainless steel A2
Rail connector Set SolidRail UltraLight and Light
Product number:
1004107
MCS Certified For quick and easy connection of two K2 SolidRail XS, UltraLight or Light. Set including screws and nuts.
K2 Clamp MC 25-40
Product number:
2004537
MCS Certified
K2 Clamp - Universal clamp for fixing solar modules with frame heights of 25-40 mm. Not compatible with the K2 Dome 6 system. Material: Aluminium EN AW 6063 T66, Thermoplastic, stainless steel A2
K2 Clamp MC 25-40, Black anodised
Product number:
2004540
MCS Certified Black anodized Universal module middle clamp for fixing solar modules with frame heights of 25-40 mm. Not compatible with the K2 Dome 6 System. Material: Aluminium EN AW 6063 T66, thermoplastic, stainless steel A2. Anodising may show slight signs of scratching due to packaging and transport.
K2 Clamp EC 25-40, black anodised
Product number:
2004545
MCS Certified Black anodized Universal module middle clamp for fixing solar modules with frame heights of 25-40 mm. Not compatible with the K2 Dome 6 System. Material: Aluminium EN AW 6063 T66, stainless steel, Thermoplastic. Anodising may show slight signs of scratching due to packaging and transport.
K2 Clamp EC 25-40
Product number:
2004543
MCS Certified
Universal module end clamp for fixing solar modules with frame heights of 25-40 mm. Not compatible with the K2 Dome 6 System. Material: Aluminium EN AW 6063 T66, Stainless steel, Thermoplastic.
BlackCover SingleRail 36
Product number:
2003523
K2 BlackCover for black covering of the rail ends of the K2 SingleRail 36 and K2 SingleRail 36 light. Length of the cover: 150 mm.
T-Bolt 28/15 M10
Product number:
1000571
T-Bolt M10x25 for insertion into the bottom chamber of K2 SolidRail. It can be inserted at any position and can be moved later if necessary. Head form: 28/15. Head dimensions: 22.5x10.5x4 mm. Thread of screw: M10x25. Material: stainlesteel A2 (1.4301)
Hexagon Flange nut with serration M8
Product number:
1000043
Hexagon flange nuts with serration M8; DIN 6923 A2 M8. The Serration prevents accidental release. Material: A2 stainless steel; Drive size:A/F 13
Hexagon Flange nut with serration M10
Product number:
1000042
Hexagon flange nuts with serration M10; DIN 6923 A2 M 10. The Serration prevents accidental release. Material: A2 stainless steel; Drive size:A/F 15.
Solar Cable Manager
Product number:
2002870
Solar Cable Manager with connecting possibility for outdoor-installation. LxW: 200x4.6 mm
External cable clip OMEGA D for solar cables
Product number:
1005394
External cable clip of solar cables for cables extending beyond K2 rails. Fixation in the C-chamber of the Profilee. Material: Polypropylen with UV stabiliser, black
EndCap for SolidRail Light
Product number:
1004765
K2 End Cap for K2 SolidRail Light 37. Material: glass fibre reinforced polyamid
EndCap for SingleRail 36
Product number:
1004767
K2 End Cap for K2 SingleRail 36, SingleRail 36 ight and CrossRail 36. Material: glass fibre reinforced PA or PA type 6
EndCap for SolidRail Medium
Product number:
1004766
K2 End Cap for K2 SolidRail Medium 42. Material: glass fibre reinforced polyamid
StairPlate Set
Product number:
2004057
The K2 StairPlate is the perfect solution for installing Micro Inverters and Optimizers from manufacturers such as SolarEdge, Huawei, BRC Solar and Enphase. With the StairPlate, these devices can be easily hooked into almost all K2 mounting rails without having to screw them directly to the roof. The units are attached to the K2 StairPlate in advance with the appropriate screws and nuts. Please note the height of the modules and the units to be used. Can only be used to a limited extent when using AddOn. Material: Stainless steel
TerraGrif K2SZ
Product number:
2001881
Mounting accessories for establishing equipotential bonding of the K2 mounting systems or for earthing the module frames. Incompatible systems:
BasicRail
(landscape mounting). Material: stainless steel 301 TA
TerraGrif K2U17 Portrait
Product number:
2000056
The mounting accessory enables potential equalisation of the K2 mounting systems or earthing of the module frames. The TerraGrif K217 can be easily attached to the underside of the module frame and is compatible with almost every module type. The material is 301 TA stainless steel and can be placed in the area of the adjacent elevation or mounting system components.
Lightning protection clamp 8mm Set
Product number:
2004922
Lightning protection clamp for clamping lightning protection cables with a diameter of 8 mm. Includes MK2 insert nut with mounting clip and M8x25 pan head screw.
Climber 36/50 Set
Product number:
2003145
A cross connector for the K2 SingleRail 36 & 50 and the K2 CrossRail 36 & 48. Nuts and bolts included. Material: aluminium EN AW-6063 T66, stainless steel A2
SolidRail CrossConnector Set
Product number:
1004110
Angle bracket set for rail cross connection to a 90° angle. Constructions suitable for K2 SolidRails Light, Medium and Alpin. Nuts and bolts included. Material: Stainless steel and PA
Universal End Clamp OneEnd
Product number:
2002514
Alternative article: 2004543Universal module end clamp with simple "click function" for fixing solar modules with frame heights of 30-42 mm. Not compatible with the K2 Dome 6 System and K2 FlatRail, SolidRail L/ LS /XL and CrossRail 62/ 90. Material: Aluminium EN AW 6063 T66 / A2 / POM
Universal Middle Clamp OneMid 30-42 mm
Product number:
2003071
Alternative article: 2004537Universal module middle clamp with simple "click function" for fixing solar modules with frame heights of 30-42 mm. Not compatible with the K2 Dome 6 System and K2 FlatRail, SolidRail L/ LS /XL and CrossRail 62/ 90. Material: Aluminium EN AW 6063 T66 / EN AW 6082 T6 / A2 / POM
Lightning protection clamp Alu 8mm - Set
Product number:
2002473
Alternative article: 2004922Lightning protection clamp for clamping Ø 8mm lightning protection cables. Including MK2 slot nut, Washer (8,4x20x1,2 mm) and stainless steel socket screw M8x30.
Standing Seam Sheet Metal
K2 mounting systems for standing seam roofs are suitable for standing seams and round seams. This system is non-penetrative and fixed with seam clamps. Clamps are available for different types of seams and manufacturers such as Kalzip or Rib-Roof.
The mounting systems at a glance:
Standing Seam Sheet Metal
Standing Seam Sheet Metal
Standing Seam Sheet Metal
K2 Base: Easy, fast and safe planning
Quick and easy planning in five steps of K2 mounting systems for pitched and flat roofs. Our free planning tool K2 Base has a dashboard for efficient project management. Google Maps integration and graphic drawing tools support you in planning and make it easier.
