Self-drilling wood screw Ø 8,0 mm
Product number:
2004110
Plate head wood construction screw 8x60 with ETA certification that ensures fast and secure installation without pre-drilling. Drive: T-Drive (T-40), material: A2 stainless steel. Manufacturer: HECO, Reisser or E.u.r.o. Tec.
Solar wood screw
Product number:
2004551_C
The solar wood screw in stainless steel is suitable for fastening solar systems or roof hooks above rafter-insulated roofs. It consists of two wooden threads that ensure a spacer screw connection. The counter batten is fixed with the lower head thread and all loads are transferred directly into the rafter via the thread. With the disc head of the screw, the roof hook can be screwed flush and permanently secure to the timber.
Self-drilling wood construction screw with disc head Ø 8.0 mm - S + P
Product number:
2004450
Flange head wood screw 8x100 with ETA certification that guarantees a quick and safe assembly without pre-drilling. Drive: T-Drive (T-40). Thread: Partial thread (80 mm). Material: stainless steel A2. Manufacturer: Schäfer + Peters
Self-drilling wood construction screw with disc head Ø 8.0 mm - Reisser
Product number:
2004451
Flange head wood screw 8x100 with ETA certification that guarantees a quick and safe assembly without pre-drilling. Drive: T-Drive (T-40). Thread: Partial thread (80 mm). Material: stainless steel A2. Manufacturer: Reisser
Self-drilling wood construction screw with disc head Ø 8.0 mm - E.u.r.o.Tec
Product number:
2003455
Flange head wood screw 8x80 with ETA certification that guarantees a quick and safe assembly without pre-drilling. Drive: T-Drive (T-40). Thread: Partial thread (48 mm). Material: Stainless steel A2. Manufacturer: Eurotec
T-Bolt 20/12
Product number:
2002035
Hammerhead screw for insertion into the side chamber of the K2 SingleRail 36 & 50 rails. It can be inserted at any position and can be moved later if necessary. thread: M8x30 mm; head shape: 20/12; head dimensions: 15.5x8.5x4 mm. Material: stainless steel A2 1.4301
Thread-forming metal screw 5.5x25
Product number:
2005033
Thread-forming hexagon head sheet metal screw 5.5x25 mm. Fastening of the CarrierRail on thin-walled metal profiles for PV systems, for chipless processing, approved for sheet steel from 0.4 mm and for aluminium from 0.5 mm to 1.25 mm thick. With building authority approval. Material: A2 stainless steel, EPDM
Self-tapping screw 6x38
Product number:
1005193
Thread-tapping screw 6x38 mm for non-cutting processing, approved for sheet thicknesses (steel and aluminium) from 0.4 mm to 1.25 mm. With General approval. Certification: abZ (de), abZ (de)
BasicClip
, ETA (eu), MCS (gb). Material: stainless steel A2, EPDM
Self-tapping screw 6x75
Product number:
2003064
The self-drilling hexagonal sheet metal screw 6x75 is used to securely screw the K2 SpliceFoot to wooden formwork. It comes including a mounted Ø16 mm sealing washer and is approved for sheet thicknesses from 0.40 to 2.00 mm for steel and 0.50 to 2.00 mm for aluminum. Clamp thickness is 1 to 40 mm on wood substructures and 16 to 55 mm on steel substructures. Material: A2 stainless steel/bimetal with an EPDM gasket.
Self-tapping metal screw 6x35
Product number:
1001622
Self-drilling hexagonal sheet metal screw 6x35 - with sealing washer. Approved for sheet thicknesses (steel and aluminium) from 0.4 mm.
Self-tapping metal screw 5.5x19
Product number:
2004432
The 5.5 x19 self-tapping screw is specially designed for aluminium façade fastenings (up to 4 mm) and ensures a reliable fastening solution. This screw is used to fix the articles 2004288 - CarrierRail AntiSlip Plate and 2004289 - Rail AntiSlip Clip. Material: A4 stainless steel. Manufacturer: Hilti.
Hilti screw anchor HUS4-HR 8x75 25/15
Product number:
2004531
The Hilti HUS4-HR screw anchor, designed for fast and cost-effective fixings in concrete, serves as a solid base for mounting the bracket to the wall. The screw anchor is made of stainless steel and has approval for fire protection (fire resistance), ETA (EAD 330232) and seismic approval category C1. Perfect for push-through installation and suitable for use in corrosive areas. Material: Stainless steel
Hilti Plastic screw anchor HRD-H 10x80 mm
Product number:
2004533
The pre-assembled plastic plug with HRD-H screw from Hilti is designed for quick and cost-effective fastening in concrete and masonry and serves as a solid base for mounting the bracket on the wall. The anchor is made of plastic and the screw is made of stainless steel. It is approved for fire protection (fire resistance) and ETA. Flexible anchoring depth (approved for 50 mm and 70 mm) Material: stainless steel, plastic
